5X(SM1313T 1.2G 1.6W Transmitter 16CH Video Audio Image Transmission1924
SODIAL
Price Comparison
Description
5X(SM1313T 1.2G 1.6W Transmitter 16CH Video Audio Image Transmission1924 5X(Item name: 1.2G 1.6W transmitter module Model: SM1313T Power: 1.6W Frequency band: 1120-1360MHz Channel customer: 16 Channel frequency: A: 1120/1120/1160/1200/1240/1280/1320/1360 (MHz), B: 1120/1120/1160/1200/1258/1280/1320/1360 (MHz) Modulation type: FM Frequency control: PLL Frequency stability: u00B1100KHz (Typ.) Frequency : u00B1200KHz (Typ.) AN Ratio: -20 u00B17dB S(Fo u00B13MHz: 70dBc Channel carrier error: 1dB Antenna port resistance: 50 ohms Input signal format: NTSC or PAL Video input level range: 1V u00B10.2Vp-p type Operating temperature: -10 u2103-+60 u2103 Output Characteristic: (25 u2103 There are heat dissipation measures) (Note: The ANT port must be connected to an antenna, and the 1.2G antenna must match and have good contact with the ANT port, otherwise it burn out the PA.) 1. Transmission power micro-power (Tx Power): -13 (Min.), -10dBm (Typ.), -8 (Max.). Test )
